62535 12 Pin Western Unimount Dual 2E Headlight Harness Kit GMC Jimmy Chevy Blazer With DRL

A new wiring setup (Western #62535) for '83-'97 GMC Jimmy and Chevy Blazers with 2E headlights and daytime running lights. If your vehicle has 2E but no DRL, you need kit 61575.  This is for Western Unimount or Fisher MM. It comes with the 12-pin relay style Control Harness 61557, Headlight Harness 63536 Western (or 8422 Fisher) and the Small Parts Bag. If you don't have the power harness, you will need to add that to the cart too.

Take a look at the headlights in your vehicle. They will have some #'s stamped in the lenses. Make sure it says 2E on the headlights. This is a 12-pin harness and requires the 12-pin lights. You can buy the light set or just get the 12-pin harness to swap your lights over.

Don't forget to add a tube of dielectric grease to protect these plugs.

Use page 77 at this link for another wiring diagram Wiring Schematics Guide.

Here is a link to the Blazer mount kit with the wiring instructions.
