816000164 Diamond Belt Drive Plow Pump Under Hood
A New old stock Diamond Under Hood Belt Drive Plow Pump. These were used on the straight blades and V plows.
These pumps are no longer made.
Here is a Diamond Under Hood Belt Drive Plow Pump. These were used on the straight blades and V plows. The Diamond part # is 8160000-164. These have an external fluid tank that we also have available. We have many of these Diamond parts available. We also have the pulley 816000-169 that goes on the front and the hose and fitting kits.
The front mounting surface has four holes. They have a 2" spread center to center, the shaft sticks out 1.5" from the face, the pump is about 5" over all length, and this has two holes with pipe thread holes.
There is a tag on the pump that says "John S. Barnes Corp Rockford, Ill. 10394 1002225".
In the casting of the pump is "2670017" on one side and "K81" on the other.
Here are some links to kits that included these pumps:
81800 Underhood Electric Solenoid Valve Slik Stik Diamond.
81801 Underhood Electric TouchPad Belt Drive Diamond Pump Kit.
