Here you are buying a New Genuine Meyer E57H Plow Pump. These are pulled out of New pump kits. This is the H model pump - 2" taller than standard height pump. The tank measures 8". These were used on the Meyer MDII, Plus mount, and Diamond plows. This uses the better 2 post motor. If you are upgrading from an E47, you will need the extra ground cable. This also has the newer angling block where the male couple comes out the side of the block. Make sure you check all these things. If you have an old style block now, you should get a set of couplers to match this new style.
This is a new pump it was in a dealer inventory and does have some scratched in the paint but was never installed.
Here you are buying a New old stock Genuine Meyer E57H Plow Pump. These are pulled out of New pump kits. This is the H model pump - 2" taller than standard height pump. The tank measures 8". These were used on the Meyer MDII, Plus mount, and Diamond plows. This uses the better 2 post motor. If you are upgrading from an E47, you will need the extra ground cable. This also has the newer angling block where the male couple comes out the side of the block. Make sure you check all these things. If you have an old style block now, you should get a set of couplers to match this new style. These kits have been on the shelf and the paint is not perfect. It does show some shelf life and Meyer did a terrible job of painting them back them.
The Diamond part # is 15866. Meyer is 15867. This pump came in several kits including 80467, 15900, 15898, and 15864.
There are the Standard or H model. (The H is 2" taller. These are used on MDII/Plus and Diamond mounts.) Tank measures 6" Regular and 8" for H.
There are also two different angling blocks. The old block has both couplers coming out the top. The new block has the male coupler coming out the side of the block. This is for the New block only.
This carriers the Meyer 1 year warranty, but before installing you must flush the cylinders and hoses and use Genuine Meyer plow oil.
Below is a list of PDF files you can click on to open:
E-57 E-57H Service / Repair /Shop Manual.
E-57/E-57H Flow Chart /Troubleshooting Guide.
15866 E-57H 12V Unit Only – Meyer.
15867 E-57H 12V Unit Only – Diamond.
15862 E-57 Carton 12V with 1.5 x 10 Rams – Slik Stik.
15863 E-57 Carton 12V with 1.5 x 12 Rams – Slik Stik.
15864 E-57H Carton 12V with 2 x 12 Rams – Slik Stik.
15882 E-57 Carton 24V with 1.5 x 10 Rams – Slik Stik.
15883 E-57 Carton 24V with 1.5 x 12 Rams – Slik Stik.
15886 E-57H Carton 24V with 2 x 12 Rams – Slik Stik.
15868 E-57 Carton 12V with 1.5 x 10 Rams – Touchpad.
15893 E-57 Carton 12V with 1.5 x 12 Rams – Touchpad.
15898 E-57H Carton 12V with 2 x 12 Rams – Touchpad.
15900 E-57H Carton 12V with 1.5 x 10 – Touchpad – Full Trip.
80467 E-57H Carton 12V with 1.5 x 10 – Touchpad – Trip Edge.
15895 E-57 Carton 24V with 1.5 x 10 Rams – Touchpad.
15896 E-57 Carton 24V with 1.5 x 12 Rams – Touchpad.
15899 E-57H Carton 24V with 2 x 12 Rams – Touchpad.
