16003 Meyer E72 12V Pump Kit with Controller

This is a Meyer E72 12V Pump Kit with Controller. Part number 16003.

Sold individually as 16006 and in the following kits: 16003, 16007, 16009, 41475 and 41350.

There's also a 24V version (16004) of this pump sold in the following kits: 16005, 16010, and 16020.

Here is a link to the parts list and installation instructions, the shop service manual, and a part breakdown of the E-72 pump.

Kit includes the following:

• 16003 - x1 - Lift and P.A. Ass'y. (Complete)
  • 16006 - x1 - Lift Ass'y. (Unit only)
  • 15645 - x1 - E-72 Lift Unit Cover
  • 15370 - x1 - Starter Solenoid - 12 volt
  • 05815 - x1 - Lift Cylinder 1.75 x 8” SAE 6
  • 22883 - x1 - Hose Ass’y SAE 1/4” x 22” Lg. M-6 Faceseal
  • 22690X - x1 - Pistol Grip Controller
  • 22691 - x1 - Universal Truck Side Harness
  • 22692 - x1 - Plow Side Harness
  • 05024 - x1 - Power Cable - 36"
  • 13333 - x1 - Hydraulic Mounting Bracket
• 07708 - x1 - Ram L.H. with Hose & Fittings
  • 07968 - x1 - Ram (1-1/2” x 10”)
  • 22885 - x1 - Hose Ass'y. SAE 1/4 x 54" Lg. M-6 Faceseal
  • 22866 - x1 - SAE 6 x 90 Degree Elbow M-6 Faceseal
• 07709 - x1 - Ram R.H. with Hose & Fittings
  • 07968 - x1 - Ram (1-1/2” x 10”)
  • 22884 - x1 - Hose Ass'y. SAE 1/4 x 33" Lg. M-6 Faceseal
  • 22866 - x1 - SAE 6 x 90 Degree Elbow M-6 Faceseal
• 08365 - x1 - Hardware Bag
  • 15634 - x1 - Cover Strap
  • 20029 - x4 - Bolt H 5/16 - 18 x 1-1/2” Gr. 2
  • 20049 - x2 - Bolt H 3/8 - 16 x 1” Gr. 2
  • 20147 - x2 - Bolt H 5/8 - 11 x 3 1/2" Gr. 5
  • 20150 - x2 - Bolt H 5/8 - 11 x 4 1/2" Gr. 5
  • 20304 - x4 - Locknut 5/16 - 18
  • 20309 - x4 - Locknut 5/8 - 11
  • 20327 - x2 - Lockwasher 3/8”
  • 21398 - x2 - S. Tapping Screw 1/4 - 14 x 3/4"
  • 22866 - x1 - SAE 6 x 90 Degree Elbow M-6 Faceseal
• 08202 - x1 - Plug Bracket Kit
  • 19607 - x1 - Plug Bracket
  • 19609 - x1 - Plate
  • 20027 - x2 - Bolt H 5/16-18 x 1 Gr. 2
  • 22658 - x2 - Bolt H 5/16-18 x 3 Gr. 2
  • 20525 - x4 - Finish Nut 5/16-18
  • 20326 - x4 - Lockwasher 5/16
