25878 Genuine Western 2x16" Heavy Weight Angling Cylinder Mount Pipe Thread

This is a New Factory Western Cylinder - not aftermarket. This is for the big 9 & 10" Heavyweight plows. This is a 2x16" angling cylinder.

This has 1" pin holes.

The cylinder is a 2"x16". The 16" is the movement of the cylinder.

In the closed position it measures 23.25" from center to center on the hole.

From end to end, the tank including the nut is 22.75".

This has the normal 1/4" pipe thread hole for a hose on the top of the cylinder in line with the pin hole.
