67960-1 Western Ultramount SnowEx 99-2007 Chevy GMC 1500 3519 Plow Mount Half Ton

Western Ultramount and SnowEx Mount (part # 67960-1.) Model 3519. This kit is for Chevy GMC 1500 only. Fits 1999+ body. Will not fit the new body, they started switching over in 2006. This is just what you see in the picture - Driver Side Mount 64087, Passenger Side Mount 64086, 2x Bolt Bars 63330, 2x Backing Spacer Plates 26061 and Bolt Bag 64088. If you have a Unimount, you can also use this mount with the 27170 Unimount adapter.

Here is a link to the parts list for this mount.

Here is a link to the Complete Western Installation Instructions for this mount.

Below is what you need for wiring:

1999-2002 -

With 2-plug  9-pin relay wiring, you need the headlight harness is 26071. Or else, you can get the light wiring kit 63394 or the truck side wiring kit 63392.

If you have 3-plug wiring with the 3-port module, you need harness 28253 or wiring kit 29048.

If you have the 3-plug wiring with 4-port module, you need 26360 & 26361 or kit 8437.

2003 and later -

If you are installing it on a 2003+, you will need the 12-pin harness. 9-pin will not work. The light harness is 64075 or the truck side wiring kits 64077.

If you have 3-plug wiring with the 3-port module, you need harness 28253 or wiring kit 29048.

If you have 3-plug wiring with 4-port module you need 26352 and 26351, or kit 27780.
