77478 New Genuine Western Suburbanite Fisher Homesteader 1x7" Angling Cylinder 56772

A New Genuine Western/Fisher Angling Cylinder #77478.

This is used on the Western Suburbanite 6'8", 7'4" and the Fisher Homesteader 6'8" and 7'4" plows. It is a 1x7" cylinder. It an updated version of the old 56772K cylinder and used as a direct replacement.

The 7" is the movement of the cylinder.

In the closed position, it measures 13.5" from center to center on the hole. In the extended position it is 20.5", hole to hole. Overall length is 14.5" in the closed position. This cylinder has 1/2" pin holes and a port on the side that is an O ring fitting. The chrome rod measures 1" across.

If you need parts for this cylinder, the gland nut is 66699K, the split ring is 56771, and the spacer is 56803.
