SnowEx 83695 Vehicle Side Harness Kit.
A New 83695 Vehicle Side Harness Kit. This is a direct replacement for the 78402, the 83695 it is cheaper and is 2' longer that the main harness in the 78402.
This is used with SnowEx spreaders VX-1500, VX-2200, VX-3200, VX-4200 and Helixx spreaders (1.5, 2.0, 3.0, 4.5, and 6.0 cubic yards), Western Striker and Tornado spreaders and Fisher Steel-Caster and Poly-Caster spreaders.
*For the Western Tornado or the Fisher Poly-caster this kit is only used if it is the newer -1 spreaders. If your spreader does not have a -1 after the part # it is an early version and, like the Blizzard Ice Chaser, it will use the 78204 harness kit.
In this kit, you will get: Vehicle Control Harness 69902, Vehicle Harness Asssembly 83690 (AKA 72057, 69903, 69904, 83689), Plug Cover 99759, Battery Cable 22511, 100 Amp fuse 95836 and Fuse Holder/Isolated Stud Block 95837. Also comes with cable ties.
Make sure you have dielectric grease. Corrosion is the most common destroyer of these plugs.
Check this link for the manual and wiring diagrams: SnowEx V-Maxx Spreaders.
For the Helixx diagrams, check this link.
| Part type | Spreader Wiring |
|---|---|
| Spreader Brand | Snowex |
| Spreader Drive Type | Electric |
| Spreader Style | Inbed |
| Spreader Feed type | Pintle / Drag Chain |
