96100085 New Snoway Down Pressure Lift Cylinder 1.5x4 Dual Acting SA19

Here is a New Aftermarket Sno-Way Dual-Acting Lift Cylinder (part # 96100085.) The aftermarket # is 1303550.

This is for Snoway plows with down pressure. You will not find a better deal on this cylinder. They had many different cylinders. We try to keep them all in stock, so make sure this is the one that you need.

This cylinder was used on the 24 series, 25 series, 28V series and HTV plows. This is considered a 1-1/2" x 4".  If they are pitted, they should be replaced as those pits take in water and will cause freeze-up in the pump.

If you are unsure if this is what you need, below is more information on this cylinder:

• It is dual-acting.
• It has a 3/4" bolt hole in either end.
• The chrome cylinder is 1-1/2" across.
• End-to-end measurement of the black housing is 10".
• Center-to-center measurement of the pin holes in the closed position is 10.5".
• The rear port comes out toward the rear and the front port is on an angle.
