B60236 Factory Blizzard Lift Cylinder 2-1/2 x 4-5/8 760LT 760SW SA3

Here is a New Factory Blizzard Lift Cylinder (part # B60236 or 60236.)

This is the lift cylinder for 2003 and later 760LT, 760LD and 760SW plows. It is a dual-acting cylinder that mounts and dismounts the plow to the truck mount. This is considered a 2-1/2x4-5/8 cylinder. If your cylinders are pitted, they should be replaced since those pits take in water and will cause freeze-up in the pump. Get some Blizzard fluid , too, while you are at it.

If you have a factory B60236 and all you need is the seal kit, that is part # B60368.

If you need the pins, we have them too. The pin for the tank end is the #B82061 5/8"x5-3/4" clevis pin. The rod end is the #B82033 5/8"x2-3/8" pin.

Blizzard had many different cylinders and we try to keep them all in stock. Make sure this is the one you need. If you are unsure, here is more information on this cylinder: it has a 5/8" bolt hole in both ends, the chrome cylinder is 1-1/4" across and the end-to-end measurement on the black housing is 10-3/4", the housing is 2-7/8" accross. The overall lenght in the retracted position is 18".
