New Fisher XLS Plow Slide Box Wing Cylinder 1-1/2x13 B60347 77476 43803
A New Aftermarket Fisher XLS Slide Box Wing Cylinder.
A New Aftermarket Fisher XLS Slide Box Wing Cylinder. This goes in the plow to slide the power wings in and out. It is a dual acting cylinder, so power in power out. This is considered a 1-1/2x13-15/16. The Fisher part # is B60347 or 60347. The aftermarket # is 1304646. If they are pitted, they should be replaced as those pits take in water and will cause freeze-up in the pump. If you are looking for this, you probably hit something and it's bent. Just a guess. Also get some fluid, while you are at it.
If you have a factory B60347 and all you need is a seal kit, that part # is B60364.
If you are still unsure, here is some more info on this cylinder.
This is dual-acting, it has a 5/8" bolt hole in either end.
The chrome cylinder is 1" across.
End to end on the black housing is 26-1/4".
Bolt hole is 26.5 center to center.
It measures 1-3/4 across the bottom of the black housing.
This also has a tube run on the outside of the cylinder.
