New Meyer V Plow Control Factory Pistol Grip 22695X V68 V70

Here is a new Factory Meyer control 22695 for the V plows. This is used with 2 pumps V68 and the V70 but this control will also work on a straight blade with the E58 plow pump.  This has a 12 pin rectangle plug on the end of the harness. It also comes with a diode 15059 that must be used on the solenoid. Failure to use this will burn out the control. We also sell a cheaper aftermarket control listed on the left.

This will plug into the Meyer harness 22691

Here is a link to the mounting options that Meyer offers for this control.

Pistol Grip Deluxe Controller 22695X
The snow plow should only be in operation when the vehicle ignition switch and the controller are in the “ON” position.
Care should be taken to insure that the controller is kept dry and free from moisture during normal operation.
When the controller is turned “On,” lights illuminate the location of the individual touch pads for the functions of the snow plow:
Up, Angle Left, Angle Right, Left Extend, Left Retract, Right Extend, Right Retract, Scoop, Vee and Down.

The 22695X controller has an auto detect feature which allows it to operate either the E-58H Straight Blade or V-70 unit V-Plow.
Lowering of the snow plow an inch at a time is possible by tapping the down arrow down direction in short intervals. Holding
down the down arrow will activate a float light located in the upper right corner of the controller. This light indicates the snow
plow is now in the Lower/Float position. In this position the snow plow will be able to follow the contour of the road and the
snow plow can also be angled to the left or right. Touching the up arrow automatically cancels the Lower/Float position.
While angling left, right or raising the snow plow if the button is pressed for more than four seconds, the operation will be cancelled.
This feature eliminates unnecessary amp draw from the vehicle charging system.
Starting in 2011, Meyer re-branded the ALM/ARM feature on its 22695X controllers to be Hands-Free
Plowing (HFP)™. If your controller is labeled “HFP,” use these directions. When activated, the Hands-Free Plowing (HFP) mode
uses the vehicle’s shift lever to control the up/down movement of the moldboard.
Pressing the HFP button on the controller will toggle you through:
• Back-drag Mode (default mode when active)
• Forward Plowing Mode
• On/Off*
Back-dragging Mode When the controller is on and you are in the conventional plow control mode, pressing the HFP button
will activate Hands-Free Plowing (HFP). The default mode for HFP is the Back-drag Mode. In the Back-drag Mode, the moldboard
will automatically lower when you put the vehicle in reverse. Put the vehicle in drive to automatically raise the moldboard.
Forward Plowing Mode To activate the Forward Plowing Mode when HFP is already on, press the HFP button once. The
moldboard will automatically lower when you put the truck into drive. When you reach the end of the run, the moldboard will
automatically raise when you put the vehicle in reverse.
To turn the HFP feature off, press the HFP button until you see the HFP light goes off.
