Used QP-126 Snowwolf Quattro wing Plow Pusher 126"

Used QuattroPlow Snow Plow #013292

This is a used QuattroPlow QP-126 snow plow in excellent condition. The plow has been fully serviced and tested and is ready to go to work. Designed for loaders weighing between 6,000 and 10,000 pounds, the QuattroPlow delivers unmatched versatility by combining four plow functions into one attachment.

The QuattroPlow's unique wing design rotates up to 165 degrees, allowing you to angle, push, backdrag, and operate in a wide-angle position without changing attachments. Whether you're clearing parking lots, loading docks, or tight commercial areas, the QP-126 helps move more snow in less time.

Installation is simple with only two hydraulic hose connections required. No additional wiring, controllers, or complicated electrical systems are needed. The aggressive moldboard curvature and 35-degree attack angle allow snow to roll efficiently, reducing horsepower requirements while minimizing windrows.

The bonus wide-angle position adds an additional 23 inches of clearing width on each side, helping you cover more ground with every pass.

Features

• Four plow functions in one attachment
• Wings rotate up to 165 degrees for maximum snow containment
• Push, angle, backdrag, and wide-angle operating modes
• Two hydraulic hose connections for quick installation
• No additional wiring or controllers required
• Excellent snow rolling design reduces horsepower requirements
• Wide-angle mode adds 23 inches of clearing width on each side
• Full down pressure compatible
• Universal skid steer compatible
• Crossover relief valve
• Fully serviced and tested

Specifications

• Plow Number: 013292
• Model: QP-126
• Blade Width: 9 ft
• Width in Pusher Position: 10 ft 6 in
• Maximum Width: 12 ft 10 in
• Width in Backdrag Position: 10 ft 6 in
• Clearing Width at Wide Angle: 10 ft 6 in
• Width in Angled Backdrag Position: 9 ft 5 in
• Blade Height: 30.7 in
• Weight: 1,301 lb
• Moldboard Material: 10-gauge steel
• Trip Springs: 4 external
• Vertical Ribs: 6
• Moldboard Radius: 14 in
• Wing Thickness: 3/8 in Grade 50 steel
• Wing Hinge Pin: 1 3/8 in x 21 1/2 in
• Wing Cylinder: 1 1/2 in x 6 in Nitro Steel double acting

The QuattroPlow QP-126 is an excellent choice for contractors and municipalities looking to maximize productivity with a single attachment. Its innovative four-function design, heavy-duty construction, and simple hydraulic operation make it one of the most versatile snow plows available for compact and mid-size loaders.
