Used QP-138 Snowwolf Quattro wing Plow Pusher 138"

Used QuattroPlow Snow Plow #013289

This is a used QuattroPlow QP-138 snow plow in excellent condition. The plow has been fully serviced and tested and is ready to go to work. Designed for loaders weighing between 6,000 and 10,000 pounds, the QP-138 is the largest model in the QuattroPlow lineup, offering exceptional snow-moving capacity and unmatched versatility.

The QuattroPlow's innovative wing design rotates up to 165 degrees, giving you four plow functions in a single attachment. Easily switch between pushing, angling, backdragging, and wide-angle containment to maximize productivity in parking lots, roadways, and large commercial properties.

Installation is simple with only two hydraulic hose connections required. There are no additional wiring harnesses, controllers, or electrical components to install. The aggressive moldboard curvature and 35-degree attack angle help roll snow efficiently, allowing you to move more snow while reducing horsepower requirements and minimizing windrows.

The wide-angle position adds an additional 23 inches of clearing width on each side, helping you clear large areas faster with fewer passes.

Features

• Four plow functions in one attachment
• Wings rotate up to 165 degrees for maximum snow containment
• Push, angle, backdrag, and wide-angle operating modes
• Two hydraulic hose connections for quick installation
• No additional wiring or controllers required
• Efficient moldboard design reduces horsepower requirements
• Wide-angle mode adds 23 inches of clearing width on each side
• Full down pressure compatible
• Universal skid steer compatible
• Standard crossover relief valve
• Fully serviced and tested

Specifications

• Plow Number: 013289
• Model: QP-138
• Blade Width: 10 ft
• Width in Pusher Position: 11 ft 6 in
• Maximum Width: 13 ft 10 in
• Width in Backdrag Position: 11 ft 6 in
• Clearing Width at Wide Angle: 11 ft 4 in
• Width in Angled Backdrag Position: 10 ft 3 in
• Blade Height: 30.7 in
• Weight: 1,345 lb
• Moldboard Material: 10-gauge steel
• Trip Springs: 4 external
• Cutting Edge: 5/8 in x 6 in top punch high-carbon steel
• Angle Rams: 2 in x 13 in Nitro Steel UltraMAX
• Vertical Ribs: 8
• Moldboard Radius: 14 in
• Full Down Pressure Compatible
• Universal Skid Steer Compatible
• Crossover Relief Valve: Standard
• Wing Thickness: 3/8 in Grade 50 steel
• Wing Wear Shoes: 1 in High Density Urethane
• Wing Hinge Pin: 1 3/8 in x 21 1/2 in
• Wing Cylinder: 1 1/2 in x 6 in Nitro Steel double acting
• PowerWing Upgrade: Optional

The QuattroPlow QP-138 is built for contractors and municipalities that need maximum productivity from their loader. With its innovative four-function design, heavy-duty construction, and nearly 14-foot maximum operating width, this plow is designed to move more snow in less time while delivering outstanding performance in every storm.
