1VP1 New Curtis Dual Acting V Plow Angling Cylinder 1 Hole Sno Pro 3000 SA35

This is a new aftermarket Curtis Dual Acting Angling Cylinder. Curtis had two different V plows. This one is for the dual acting cylinder plow. They also have a V plow that had spring return wings. If you have that, you need cylinder 1TBP27. This cylinder was used on the Curtis V plow. It is a dual acting cylinder. This is part # 1VP1.

This has 1" pin holes.

In the closed position it measures 18.5" from center to center on the hole.

The overall length of the cylinder in the closed position is 20".

This has the normal 1/4" pipe thread hole for a hose in the front and back of the cylinder. The ports are in the top in line with the pin holes.

The rod end is 1.5" and the base end is 1.75"at the flat spots.
