52635 SnowEx HDV V Plow New Genuine SnowEx 1-3/4 x 11 Dual Acting Angling Cylinder 1" Hole

A New Genuine SnowEx Dual Acting Angling Cylinder for the HDV V plows. This is considered a 1-3/4x11" cylinder. The Snowex part # 52635. This uses the O ring style fittings. There is a port on the left and right of the pin hole on the back. One side is plugged and on the top in the front of the cylinder.  Other than being red this is the same as a Western 44340 and Fisher 44341.

This is a low friction cylinder. They do not use a compression packing, but an O ring sealed nut.

This has 1" holes for the pins. Center to center on the pin holes when closed is 18 1/4",

The tank is 17 from end to end including the nut.

The chrome rod is 1.5" across.

There are ports in the back on both sides that are flush and one towards the front that is raised both O-ring style and used fitting 56615-1.

If you need to repair a cylinder the gland nut is 48985 or seal kit 84832.
