52635 Aftermarket SnowEx HDV V Plow New 1-3/4 x 11 Dual Acting Angling Cylinder 1" Hole SA30

A New Aftermarket Snowex Dual-Acting Angling Cylinder for the HDVV plows. This is considered 1-3/4x11". This cylinder is used on all the newer V plows. Replaces SnowEx part number 52635. This uses the O-ring style fittings. There is a port on both sides in the back and on the top in the front of the cylinder. This is also used by Western, but they use part # 44341.

This is a low friction cylinder. They do not use a compression packing, but an O ring sealed nut.

This has 1" holes for the pins. Center to center closed length on the pin holes is 18 1/4".

The tank is 18" from end to end including the nut (slightly longer than the OEM housing).

The chrome rod is 1.5" across.

There is a port in the back that is flush and one towards the front that is raised - both O-ring style.
