61920 New 83-93 Chevy GMC Blazer Jimmy S-10 Western Unimount Model 1535

A New Unimount for a 1983-1994 Chevy Blazer and S10 truck. These are no longer available from Western. If you have a 1994+, you have to use the 62200 mount. You get just what you see - the main clevis, the four lugs and the shield. If you need more parts, add them to your cart.

This mount does not come with bolts or link arms. The link arms for the Blazer are special for the Blazer only #62246. Most of the bolts are all normal, but if you don't have the nut bars (part # 61486), you will need them for the front bolts, too. The lug #s are 61916 and 61917.

The link below has a complete list of the needed hardware, if you want to pick it up on your own.

Chevy GMC S10 Blazer GMC Jimmy 1983+ 1505 62200 installation instructions and parts list.

If you need headlight wiring, we have them listed below. You need to check what lights you have.

2B Single Glass Sealed Beam Kit 61545 83-97 Chevy Blazer.

2E Blazer Headlights Kit 61575 83-97 Blazer.

HB3-HB4 Headlights Kit 61515 83-97 Only Chevy Blazer.

HB3-HB4 Headlights for 98+ Blazers only.
