New Genuine Western / Fisher Angling Cylinder 64297 Dual Acting for V Plow.
A New Genuine Fisher 64297 / Western 56546 Dual Acting Angling Cylinder for the Fisher EZ V Plow. This is the early version with pipe thread. This is considered a 2x10" cylinder used on the early V plows. This later version was O ring style fitting we sell those as well and that was part # 56709W / 56709F.
This has 1" holes for the pins. Center to center closed on the pin holes is 17 3/8".
The tank is 16" from end to end including the nut.
The chrome rod is 1.5" across.
There is port in the back that is flush and one towards the front that is raised - both are Pipe thread style.
Some history on this cylinder:
The Fisher EZ-V pump kit is part # 9828. When they do revisions to the kits, they add a -1 or -2 as they go. So, the original 9828 came with the dual acting cylinder 66375 with a pipe thread fitting. Then the 9828-1 was an upgraded cylinder 56546 - also pipe. This was also replaced with kit 9828-2 which was a change in the lift cylinder from a pipe to an O ring fitting. Then for the 9828-3 they changed the angle cylinder again to 64297. The last and newest kit had the O ring style cylinder 56709. The 56709 is what we are selling here. It is a direct replacement of the earlier cylinders with the exception being that the fittings need to be changed over to O ring style, if you still have the old pipe thread. Â
