56709 Fisher EZ-V Plow New 2x10 Dual Acting Angling Cylinder 1" Hole Pipe Fitting SA29

We sell this with two different fitting types - both pipe thread and O-ring fittings. This listing is for 1/4-20 Pipe fittings.

This is a New Aftermarket Fisher Dual Acting Angling Cylinder for the Fisher EZ V Plow. This is considered a 2x10" cylinder used on the early V plows. They used Fisher part # 56709F. This one uses the 1/4" pipe fitting. The SAM part # is 1304217.

This has 1" holes for the pins. Center to center closed on the pin holes is 17 3/8".

The tank is 16.5 from end to end.

The chrome rod is 1.5" across.

There is a port in the back that is flush and one towards the front that is raised - both 1/4-20 pipe fitting.

Some History on this Cylinder

The Fisher EZ-V pump kit is part # 9828. When they do revisions to the kits, they add a -1 or -2 as they go. So the original 9828 came with the dual acting cylinder 66375 with a pipe thread fitting. Then, the 9828-1 was an upgraded cylinder 56546 - also pipe. This was also replaced with kit 9828-2 which was a change in the lift cylinder from pipe to o-ring fitting. Then for the 9828-3, they changed the angle cylinder again to 64297. The last and newest kit had the O-ring style cylinder 56709. The 56709 is what we are selling. It is a direct replacement of the earlier cylinders with the exception being that the fittings need to be changed over to O-ring style if you have the old pipe thread yet.
