56709 Fisher EZ-V Plow New 2x10 Dual Acting Angling Cylinder 1" Hole O Ring Fitting SA17

We sell this with two different fitting types - both pipe thread and O ring fittings. This listing is for O ring fittings.

This is a new aftermarket Fisher Dual Acting Angling Cylinder for the Fisher EZ V Plow. This is considered a 2x10" cylinder used on the early V plows. They used Fisher part # 56709F. This one uses the O ring style fitting - not the 1/4-20 fitting that the older cylinders had. The SAM part # is 1304217.

This has 1" holes for the pins. Center to center closed on the pin holes is 17 3/8".

The tank is 16.5 from end to end.

The chrome rod is 1.5" across.

There is a port in the back that is flush and one towards the front that is raised. Both are O-ring style.

Some History on this Cylinder:

The Fisher EZ-V pump kit is part # 9828. When they do revisions to the kits they add a (-1) or (-2) as they go. So, the original 9828 came with the dual acting cylinder 66375 with apipe thread fitting. Then the 9828-1 was an upgraded cylinder 5654 - also pipe. This was also replaced with kit 9828-2 which was a change in the lift cylinder from pipe to O ring fitting. Then for the 9828-3 they changed the angle cylinder again to 64297. The last and newest kit had the O ring style cylinder 56709. The 56709 is what we are selling here. It is a direct replacement of the earlier cylinders with the exception being that the fittings need to be changed over to O ring style, if you have the old pipe thread still.
