7144 Chevy GMC Truck 1991-01 C3500 HD 2WD Straight Axle Fisher Minute Mount Plow
Plow Mount 7144 2WD Chevy GMC. Fits Fisher plows.
A New Fisher Plow Mount 7144 for the Minute Mount 2. This is for the 1991-2001 Chevy GMC 2WD C3500 HD. This is not for the NON-HD, this is for a 2WD HD truck only, if you do not have an HD you need mount # 7148.
With this mount you get: Driver Side Push Plate 20557, Passenger Side 20558, Angle Brace 8661, Backing Plate 7892, 2x Bolting Bars 7928 and Bolt Bag 7144.
Here is a link to the Parts List and Installation Instructions.
If you also need Headlight wiring, here is a chart to help.
Relay wiring -
For 2B single glass sealed beams with Daytime Running Lights (DRL), you need harness 61556 or kit 61555). Without DRL, you need 61546 harness or 61545 kit.
For HB-3/HB-4 plastic lenses with replaceable bulbs and DRL, you need harness 61586 or kit 61585). Without DRL, you need 61716 harness or 61515 kit.
For LF/UF glass sealed beams with DRL, you need harness 61581 -Modified or kit 61560. Without DRL, you need harness 61581 or kit 61580.
4 port module -
For 2B single glass sealed beams, you need kit 8439 or harness 26353 & 2635.
For HB-3/HB-4 plastic lenses with replaceable bulbs, you need kit 8438 or harness 26352 & 26351.
For LF/UF glass sealed beams, you have kit 28400 & B62225-1 or harness 28244, 28242 & B62225.
3 port module -
For 2B glass sealed beam 3-port, you need harness 28464 or kit 29051.
For HB-3/HB-4 Plastic Lens with replaceable bulbs, you need harness 28253 or wiring kit 29048.
For LF/UF glass sealed beams, you need kit 29049 & B62225-1 or harness 28986 & B62225.
2001, CHEVY/GMC, C3500 HD
2000, CHEVY/GMC, C3500 HD
1999, CHEVY/GMC, C3500 HD
1998, CHEVY/GMC, C3500 HD
1997, CHEVY/GMC, C3500 HD
1996, CHEVY/GMC, C3500 HD 2WD W/STRAIGHT FRAME
1995, CHEVY/GMC, C3500 HD 2WD W/STRAIGHT FRAME
1994, CHEVY/GMC, C3500 HD 2WD W/STRAIGHT FRAME
1993, CHEVY/GMC, C3500 HD 2WD W/STRAIGHT FRAME
1992, CHEVY/GMC, C3500 HD 2WD W/STRAIGHT FRAME
1991, CHEVY/GMC, C3500 HD 2WD W/STRAIGHT FRAME
Truck Manufacturer | Chevy/GMC |
---|
