Truck Side 3 Plug Wiring Kit Western Fisher 3 port 3 Plug
From $770.00
To $1,017.80
In stock
Western, Fisher, SnowEx Complete Truck Side 3-plug Isolation Module Wiring Kit. No control.
To determine what you need for your truck, use the Western, Fisher or SnowEx quick match system to determine what you need. Some trucks require an additional adapter but not all do. If you have an additional harness listed select it below, if not leave them blank.
Above, you must select the module and adapters you need. If you do not know what you need, you must use the Western Power Match to figure that out. Some may call for extra adapters. If they are not listed with the kit, it may not come with it. Please ask.
This is the complete Truck Side Wiring Kit for Western and Fisher plows. This is the 3-port isolation module and the 3-plug set up. If you have a 2-plug plow and you want to convert it, you will need the plow side #28053 to use this. You will also need the control, if you don't have it already.
What you will get is the 3-port module, 63411 Truck Side Power Cable, 26345 3-Pin Control Harness (Straight Blade) or 26346 7 pin control harness,(V Plow), 11-pin Truck Side Light Harness, 56131 Motor Solenoid, 22511 Power Wire, 29047 3 Port Module Adapter and then your choice of headlight adapter to fit your truck. We also recommend getting a tube of dielectric grease to protect these plugs.
If your plow is 2-plug, you also need kit 28053 to convert it to the 3-plug.
Note: Western now has a multiplexing wiring system. If you have a 4-pin control instead of six, and two grille plugs instead of three, then this wiring will not work for you.
Click here to use the Western Power Match to get the correct light harness.
Here is a link to the Western Wiring Schematics Guide.
