05752 Aftermarket Meyer HM Plow 2" x 12" Angling Ram Cylinder 1304015

A New Aftermarket Angling Cylinder # 1304015.

This cylinder will replace the factory Meyer cylinders # 05752 and # 07707 used on the Meyer HM plows. They can also be used on most C blades if you want larger cylinders.

The measuring system is often misunderstood. This is a 2x12" angling cylinder. The 2" is telling you the size of the rod, and then the 12" is giving you the movement. So it would be the difference between full open (31.5") and full closed (19.5") or 12" movement. These have a 5/8" hole in either end of them. There is a port on the side for a 1/4 pipe thread for the hose. We also have some available with the o-ring fittings. (If you measure center to center of the bolt holes, it is 18" fully closed.)
