Genuine Meyer 2x12 Power Angling Cylinder Set With Hoses 07024, 07023, 05752

This is a Set of New Genuine Meyer 2x12" Power Angling Cylinders for a Meyer plow. The part # for the cylinders is 05752. The part # for these with the hoses as an assembly like this is 07024, and 07023.

These are the heavy duty ones used on the Meyer HM plows. They can be used on most C (commercial) blades, if you want larger cylinders. These are new cylinders we pulled out of new pump kits, but they may have scratches on them.

We also have 1.5x10 and 1.5x12 cylinders. These cylinders are often pitted and at that point they should be replaced as those pits take in water and will cause freeze-up in the pump. Get a new set on there and flush all the fluid out. We have the hoses listed here for the swap.

Meyer has a few cylinders, so make sure this is what you need. This style has been used since the late 70's.

The measuring system is often misunderstood. This is a 2x12" angling cylinder. The 2" is telling you the size of the rod, and then the 12" is giving you the movement. So it would be the difference between full open (31.5") and full closed (19.5") or 12" movement.These have a 5/8" hole in either end of them. There is a port on the side for a 1/4 pipe thread for the hose.  We also have some available with the O-ring fittings. ( If you measeure center to center of the bolt holes it is 18" fully closed.)

They also sold them with hoses and couplers using parts #'s 07023 and 07024.

Buyers / SAM uses #1304015 for the aftermarket version.
