13608 Meyer Commercial A Frame Classic C Series Blade 15x31x23.5

New Genuine Meyer A-frame (part # 13608.) This is a 15" A-frame for the C and CP series plows. Fits C7.5 -C9 blades. This is for the Meyer EZ Classic mount. The measurements on this are 15x31x23.5. The 15" is from the front bolt to the slide point, the 31" is the length and center to center across the mounting tabs is 23.5". There are two versions of this A-frame. One is for 10" cylinders and the other uses 12" cylinders. This is for the 12" cylinders. So if you have 10's, you need to change the cylinders, too. Or else, you can use the A-frame for the 10" cylinders (part # 13770). They are cheaper too.

This 13608 A-frame came in the 16504 S.A.F. kit.

Here is a link to the Meyer instructions for this A-frame. For help with measuring your A-frame, please refer to this Measuring Guide.
