20116K Genuine Fisher 1.5x10 Lift Cylinder 1 Hole Minute Mount 1 Pipe Thread RD HD EZ-V

This is a New Factory Fisher Lift Cylinder. This one was commonly used with the older MM1 plows. It was also the lift cylinder on the MM1 EZ-V plow. There was more than one option through the years, so make sure it is the correct one. We have others, if it is not. The Fisher part # is 20116. We have an aftermarket option too.

This has 1" pin holes.

The cylinder is a 1.5"x10". The 10" is the movement of the cylinder.

In the closed position, it measures 17" from center to center on the hole.

From end to end, the tank including the nut is 16.5".

This has the normal 1/4" pipe thread hole for a hose on the side of the cylinder in line with the pin hole.
