56750 MVP V Plow New Western Ultramount 2x11 Dual Acting Angling Cylinder 1" Hole SA16

A New Aftermarket Western Dual-Acting Angling Cylinder for the MVP V Plow on the Ultramount frame. The Western part # is 56750 and the SAM part # is 1304204. This is considered a 2x11" cylinder used on the early V plows. If you have the older Western Unimount V plow, you need the 2x10 cylinder that we have available too.

This has 1" holes for the pins.

Center to center closed length on the pin holes is 18 1/4".

The tank is 17" from end to end.

The Chrome rod is 1.5" across.

There is a port in the back that is flush and one towards the front that is raised.
