44341 Aftermarket MVP Plus, MVP3 V Plow New Western 1-3/4 x 11 Dual Acting Angling Cylinder 1" Hole SA30

A New Aftermarket Western Dual Acting Angling Cylinder for the MVP Plus & MVP3 V plows. This is considered a 1-3/4x11" cylinder used on all the newer V Plows. Replaces Western part # 44341. This uses the O-ring style fittings. There are ports on both sides on the back and on the top in the front of the cylinder.  This is also used by Fisher, but they use part # 44340.

This is a low friction cylinder. It does not use a compression packing but an O-ring sealed nut.

This has 1" holes for the pins. Center to center closed length on the pin holes is 18 1/4".

The tank is 18 from end to end including the nut (slightly longer than the OEM housing.)

The chrome rod is 1.5" across.

There is a port in the back that is flush and one towards the front that is raised - both O-ring style.
