69892-1 Dodge Ram 7 Wire, 11 Pin Wiring Harness Kit for 3-Port Isolation Module Western Fisher Blizzard Snowex

Truck Side Wiring Kit # 69892-1.  This is an updated version, a direct replacement for 69892, it just has better sealed relays. This is for 3-port modules only. This is the newer kit used on Dodge truck. This kit gets tapped into the wires that Dodge provides under the fuse block, there is no need to pull the front of the truck apart with this kit.

This kit will not work on a Dodge Power Wagon, they did not come with the same set up under the body control module. If you want to do it the normal way where it plugs into the back of the lights and you have the HID lights you need 69804. For Non-HID you need 29049 and 69826-1.

*NOTE : If you have a plow that has the old glass sealed beams you also need additional power harness 72641.

With this kit you get 11-pin light harness w/ relays 69886-1 and plug-in harness 69986. If you are replacing a bad harness, you may only need a single harness, we sell them too.  We have all the others kits available, too.

 * Our installers have found it better to remove the headlight to tap in rather than remove the distribution box.

Click here to use the Western Power Match to make sure you get the correct light harness.

The installation instructions can be found at this link.
