Used 80-91 Ford F-150 F250 F350 Bronco Truck 4x4 Western Unimount 1345 Box 61400

This is a used Western Unimount for a 1980-1991 Ford Bronco, F150, F250, F350 2x4 and 4x4, and Super Duty. The model # is 1345 and the box # is 61400. With this used mount, you will get Mount Frame 61401, Thrust Frame 61394, Spreader 61390, Spreader 61391, 61726 Mount Bar and 61727 Mount Bar, and the 2 Gussets 61724 and 61725.

Note: This does not have hardware. There is a bolt kit available that is 61413, but it is mostly normal bolts. There are four nut bars that are needed for the mount. They do not come in the bolt kit, but we have them too. You need two for each side - 61652 for driver side and 61653 for passenger side. If you need the 1" lower pins, add them also. Make sure you have the link arm kits to hold the lift frame back.

This series truck had two headlight options: 2B1 and HB1.

If you have the 2B1, you need wiring kit 61545 or you can just get the light harness 61546.

If you have the HB1 lights you need wiring kit 61570 or just get the light harness is 61571.

Here is a link to the instructions for this mount 61400.
