This is a new Curtis Lift Cylinder. This cylinder was used on the Sno Pro 3000 plows. It is part #1TBP44A. This is a 1.5x7.5 cylinder. Check your Cylinder Measurements cause there was more than 1 lift cylinder option.Â
They also had a 1TBP44 without the A. That is a 1.5x7 instead of 1.5x7.5.
This has a 1" pin hole in the rod end and a 3/4" pin hole in the base end.
The cylinder is a 1.5"x7.5". The 7.5" is the movement of the cylinder. In the closed position it measures 15" from center to center on the hole.
From end to end it is 16.75".
This has the normal 1/4" pipe thread hole for a hose. The port is in the top in line with the pin hole.
